IP20 Adhesive Flexible 3014 SMD Light Strip Color Changeable CW WW 2700K-6500K CRI97
Quick details
1. LED chip:SMD3014.
2. Standard Reel Length: 5meter/roll, also can be customized.
3. Cutted: you can cut this stuff pretty easily with wire cutters
DC24V: cutted per 6LED, there are cut-lines every 25mm.
4. Power: 20W/M.
5. Power supply:
DC12V led strip: you must use a 12V DC power supply to connect this strip, do not use higher than 12V
DC24V led strip: please use 24V DC power supply.
6. Waterproof rating:
IP20:non-waterproof
IP65:drop glue waterproof
IP65:nano waterproof
IP67:silicone tube waterproof
IP68:glue-injection waterproof
7. Install: non-waterproof: with 3M adhesive on back side for sticky;
waterproof: screw+silicon clip, or 3M adhesive back side.
8. Life-span: more than 50,000 hours
9. Packing:usually 5meter/roll, 1roll/bag
black reel/white reel,anti-static bag
Technical parameters
| Item Type | SMD3014 LED Strip |
| Led Qty | 240 Leds/M |
| Voltage | DC24V |
| Cutting size | 25mm |
| Power | 20W/M |
| Ra | 97+ |
| Color | CW+WW 2700~6500K |
| PCB Color | White |
| PCB width | 10 MM,two-wire copper circuit boards |
| IP Rating | IP20 |
| Beam Angle | 120° |
| Certification | CE/ROHS |
| Warranty | 3 years |
Product specification:
| Ordering Code | Colors Available | LED features | LED
Q’ty/m | PCB | Voltage
(VDC) | Max Power
(W/m) | Waterproof Grade available (IP) |
| PS3014WW 24240-T | 2700~6500K | Sanan3014 12-14LM | 240led | 10mm white 3ounce | 24VDC | 20W | IP20 |
Applications:
1)Architecture car or home decoration;
2)Light boxes and billboards backlighting;
3)Channel letters backlighting;
4)Advertising signs backlighting;
5)Amusement park, theater and aircraft cabin mood lighting;
6)walkway, stairway, hallway lighting.etc
